The kicker base unit got most of the attention when Harken redesigned the ILCA vang system for 2026, and fairly so, but the top block changed too. Here's what's different about the new Harken 25mm Fly, and whether it's worth swapping out a block that probably still looks fine.
Why the Top Block Matters
The top block sits at the anchor point of the whole system, which means it takes the highest load of any single component in your kicker.
Whether you're running 15:1 or backing it off to 12:1, the mechanical advantage that makes the control line manageable in your hand is the same mechanical advantage stacking load onto the block at the top. A modern ILCA sailor pulling hard generates loads the original hardware was never specified for, which is the same reason Harken rebuilt the base unit.
There's also a second issue. The old vang key had a habit of working loose or dropping out when the system went slack, which is exactly what happens between tacks and on the run. Anyone who has sailed an ILCA for a few seasons has either lost a vang key or watched someone else lose one.
What's Changed on the New Harken High Load Block
The new part is the Harken 25mm Fly Block with ILCA kicker key, part number 1250.ILCA. It replaces the previous class legal top block in the redesigned system.
The load rating is the headline as it handles a 275kg maximum working load with a 550kg breaking load, in a block that weighs 43 grams and measures 65mm long. That's the strength without mass idea Harken have built the Fly range around, and on a boat where you're already hiking to hold it flat, 43 grams in the right place is worth having.
The sheave runs on stainless steel bearings in stainless races, so it should remain smooth under load after a couple of seasons. An angled pin also solves the vang key problem, as it’s shaped to hold its position even when the kicker goes slack.
The profile is low and compact so there’s less to snag, less windage, and it sits closer to the tang. The block takes a maximum 5mm line, which covers the standard ILCA kicker primary.
How It Fits the Rest of the Harken System
All three parts of the ILCA kicker were redesigned together for 2026: the vang/kicker base unit, this top block, and the Zircon twisted fiddle middle block.
You can run the new top block with your existing base and middle blocks. Nothing about it demands the full set, and plenty of sailors will upgrade in stages as parts wear out or budget allows. But the three were designed around each other, and the system works best complete.
If you're building the whole thing from scratch, start with the base unit. That's where the biggest usability gains are, particularly the cleat that releases under load. The top block is the upgrade that matters most if you're sailing at the loads where the old one was marginal.
Is It Worth Upgrading?
Honestly, it depends on what your current block is doing. If your existing top block is running smoothly and your vang key stays put, there's no urgency. The previous generation top block is still class legal, still available, and now discounted. Plenty of sailors will get more seasons out of what's already on the boat.
Upgrade if your vang key has fallen out (or you check it obsessively because it might) or the block feels notchy or gritty when you grind the kicker on. Same goes if you're sailing at a level where you're pulling maximum kicker regularly and you'd rather not think about the load rating.
This is the most expensive single block in an ILCA kicker system, and it's a significant step up from the part it replaces. What you're paying for is the load rating, the bearing quality and the pin design. If none of those three things is a problem for you right now, buy the old one and put the difference towards a sail.
Browse the full ILCA kicker and vang collection or go straight to the Harken 25mm Fly Block with ILCA kicker key.
FAQs
Is the Harken 25mm Fly block class legal for ILCA?
Yes. It's fully class legal and it's the top block in Harken's redesigned 2026 ILCA kicker system, so you can race it without checking anything.
What load can the Harken ILCA top block take?
275kg maximum working load and 550kg breaking load, in a block weighing 43 grams. It takes line up to 5mm.
Do I need the whole new Harken kicker system, or can I just replace the top block?
You can replace just the top block because it works with existing base units and middle blocks. The three parts were designed together and work best as a set, but upgrading in stages is fine and it's what most sailors do.
What's the difference between the new Harken top block and the old one?
The new 25mm Fly is a higher load rating in a lighter, lower profile body, running stainless bearings in stainless races. The main practical difference is the angled pin, which holds position when the kicker goes slack, so the vang key doesn't work loose the way the old one could.
Where does the top block sit in an ILCA kicker?
At the top, attached to the boom tang by the vang key. It's the anchor point for the whole purchase system, which is why it carries the highest load of any single block in the kicker.
